Keygeek Y3x
Keygeek Designer
Standard ProfileLinear5
Switch Overview
In theory, the Y3X switch is not an upgrade to the Y3 switch. Y3X and Y3 cover different sound and typing spectra. Compared to the classic Y3 switch, Y3X is slightly louder and poppier. Thanks to the spherical stem tip and spherical bottom housing contact point (Same as Keygeek Butterfly Switch), Y3X has a mellower and softer bottom-out feel than Y3. In general, if you are looking for a switch that is creamy and thocky, Y3 would be the go-to option. If you want your keyboard to sound thocky and poppy at the same time, this is what Y3X was designed for. Designer: MZ StudioStem Material: M5 POM (Spherical Stem Tip) Bottom Housing Material: PA66 (With spherical contact point)
Last Updated: March 14, 2026
Physical Specifications
Physical Specifications
Actuation Force32±5g/40±5g /48±5g/53±5g
Bottom Out Force37±5g/45±5g/53±5g/63.5±5g
Pre-travel2.0mm
Total Travel3.8±0.1
Stem MaterialM5 POM (Spherical Stem Tip)
Factory LubedYes
SpringKOS extended single-stage spring Factory lubed New stem design for a loud and thocky sound profile Firm but not stiff bottom out feel A linear switch with smooth travel Factory lubed and ready to use
DesignerMZ StudioStem Material
Profile Information
ProfileStandard Profile
TypeLinear
SilentNo
Pin Count5
